YOKOGAWA AAM21-S2 CENTUM CS Thermocouple RTD Input Module

Key specifications

Style: S2 (as collected; GS 33G06K40-01E does not list style codes)
Option code: /RJ = Temperature Compensation Module for Thermocouple Input
Input signal: mV -50 to 150 mV; thermocouple K, T, J, E, B, R, S, N; RTD JPt100/Pt100 3-wire 0 to 333 ohm; potentiometer
Installation: AMN11 Nest for Analog I/O Modules; up to 16 modules per nest
Signal isolation: Input signals isolated between systems; withstanding voltage 1500 V AC/min

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	YOKOGAWA AAM21-S2 CENTUM CS Thermocouple RTD Input Module
Brand	YOKOGAWA
Model	AAM21-S2
Category	PLCs & I/O
Style	S2 (as collected; GS 33G06K40-01E does not list style codes)
Option code	/RJ = Temperature Compensation Module for Thermocouple Input
Input signal	mV -50 to 150 mV; thermocouple K, T, J, E, B, R, S, N; RTD JPt100/Pt100 3-wire 0 to 333 ohm; potentiometer
Installation	AMN11 Nest for Analog I/O Modules; up to 16 modules per nest
Signal isolation	Input signals isolated between systems; withstanding voltage 1500 V AC/min
Data update period	100 ms
Current consumption	150 mA or less (5.0 V DC)
