XINJE XD-E4AD XD Series 4-ch Analog Input Expansion Module
- Brand
- XINJE
- Model
- XD-E4AD
- GEARWELL SKU
- GWP-000023470
- Category
- PLCs & I/O
Key specifications
- Resolution
- 14 bit
- Current input
- 0~20 mA, 4~20 mA, -20~20 mA
- Voltage input
- 0~5 V, 0~10 V, -5~5 V, -10~10 V
- Conversion speed
- 2 ms per channel
- Overall accuracy
- 1 %
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | XINJE XD-E4AD XD Series 4-ch Analog Input Expansion Module |
|---|---|
| Brand | XINJE |
| Model | XD-E4AD |
| Category | PLCs & I/O |
| Resolution | 14 bit |
| Current input | 0~20 mA, 4~20 mA, -20~20 mA |
| Voltage input | 0~5 V, 0~10 V, -5~5 V, -10~10 V |
| Conversion speed | 2 ms per channel |
| Overall accuracy | 1 % |
| Module power supply | DC 24 V ±10 %, 150 mA |
| Analog input channels | 4 |
| Operating temperature | 0~60 °C |
