XINJE XC3-14R-E XC3 Series PLC Basic Unit
- Brand
- XINJE
- Model
- XC3-14R-E
- GEARWELL SKU
- GWP-000023763
- Category
- PLCs & I/O
Key specifications
- Inputs
- 8 (DC24V, NPN) points
- Outputs
- 6 (relay) points
- Evidence
- XINJE manual PC01 20210906 3.4 (XC series user manual, hardware), xinje.com download center
- Communication
- Port 1 RS-232 (port 2 not on XC3 14-point units)
- Processing speed
- 0.5 us
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | XINJE XC3-14R-E XC3 Series PLC Basic Unit |
|---|---|
| Brand | XINJE |
| Model | XC3-14R-E |
| Category | PLCs & I/O |
| Inputs | 8 (DC24V, NPN) points |
| Outputs | 6 (relay) points |
| Evidence | XINJE manual PC01 20210906 3.4 (XC series user manual, hardware), xinje.com download center |
| Communication | Port 1 RS-232 (port 2 not on XC3 14-point units) |
| Processing speed | 0.5 us |
| Ambient temperature | 0 to 60 °C |
| Rated supply voltage | AC100-240 (allowable AC90-265), 50/60 Hz V |
| Type designation key | XC3 = series; 14 = I/O points; R = relay output (NPN input); E = AC power supply |
| Max power consumption | 15 (16 points and below) W |
| User program capacity | 128 KB |
