VAISALA HMD82 HMDW80 Duct Humidity and Temperature Transmitter
- Brand
- VAISALA
- Model
- HMD82
- GEARWELL SKU
- GWP-000022587
- Category
- Pressure, Flow & Temperature
Key specifications
- Output signal
- 4...20 mA, loop powered
- Supply voltage
- 10...28 (0 Ω load) / 20...28 (600 Ω load) VDC
- Humidity sensor
- INTERCAP, user exchangeable
- Enclosure rating
- IP65
- Temperature sensor
- Pt1000 RTD
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | VAISALA HMD82 HMDW80 Duct Humidity and Temperature Transmitter |
|---|---|
| Brand | VAISALA |
| Model | HMD82 |
| Category | Pressure, Flow & Temperature |
| Output signal | 4...20 mA, loop powered |
| Supply voltage | 10...28 (0 Ω load) / 20...28 (600 Ω load) VDC |
| Humidity sensor | INTERCAP, user exchangeable |
| Enclosure rating | IP65 |
| Temperature sensor | Pt1000 RTD |
| Temperature output range | -40...+60 °C |
| Relative humidity accuracy | ±3 (0...90 %RH), ±5 (90...100 %RH) at +10...+30 °C %RH |
