VAISALA HMD62 HMD60 Series Duct Humidity and Temperature Transmitter
- Brand
- VAISALA
- Model
- HMD62
- GEARWELL SKU
- GWP-000022586
- Category
- Pressure, Flow & Temperature
Key specifications
- Power supply
- 10 ... 35 VDC (RL = 0 ohm); 20 ... 35 VDC (RL = 600 ohm)
- Analog outputs
- 1 x RH 4 ... 20 mA, 1 x T 4 ... 20 mA
- Humidity sensor
- HUMICAP R2 (HUMICAP 180V option)
- Temperature sensor
- Pt1000 RTD Class F 0.1 IEC 60751
- Humidity measurement range
- 0 ... 100 %RH
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | VAISALA HMD62 HMD60 Series Duct Humidity and Temperature Transmitter |
|---|---|
| Brand | VAISALA |
| Model | HMD62 |
| Category | Pressure, Flow & Temperature |
| Power supply | 10 ... 35 VDC (RL = 0 ohm); 20 ... 35 VDC (RL = 600 ohm) |
| Analog outputs | 1 x RH 4 ... 20 mA, 1 x T 4 ... 20 mA |
| Humidity sensor | HUMICAP R2 (HUMICAP 180V option) |
| Temperature sensor | Pt1000 RTD Class F 0.1 IEC 60751 |
| Humidity measurement range | 0 ... 100 %RH |
| Temperature accuracy at +20 °C | ±0.1 °C |
| Temperature measurement range | -40 ... +80 °C |
| Humidity accuracy (0 ... +40 °C, 0 ... 90 %RH) | ±1.5 %RH |
| Operating temperature, electronics | -40 ... +60 °C |
