VAISALA HMD60T HMD60 Duct Temperature Transmitter
- Brand
- VAISALA
- Model
- HMD60T
- GEARWELL SKU
- GWP-000022584
- Category
- Pressure, Flow & Temperature
Key specifications
- Housing
- Cast aluminium electronics, stainless steel probe, IP65 (NEMA 4)
- Measurement
- Temperature only
- Output signal
- 4 ... 20 mA (2-wire, loop powered)
- Supply voltage
- 10 ... 35 VDC (RL = 0 ohm); 20 ... 35 VDC (RL = 500 ohm)
- Temperature sensor
- Pt 1000 RTD Class F0.3 IEC 60751
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | VAISALA HMD60T HMD60 Duct Temperature Transmitter |
|---|---|
| Brand | VAISALA |
| Model | HMD60T |
| Category | Pressure, Flow & Temperature |
| Housing | Cast aluminium electronics, stainless steel probe, IP65 (NEMA 4) |
| Measurement | Temperature only |
| Output signal | 4 ... 20 mA (2-wire, loop powered) |
| Supply voltage | 10 ... 35 VDC (RL = 0 ohm); 20 ... 35 VDC (RL = 500 ohm) |
| Temperature sensor | Pt 1000 RTD Class F0.3 IEC 60751 |
| Temperature measurement range | -20 ... +80 °C |
| Operating temperature, electronics | -5 ... +55 °C |
