TURCK 7545077 MK91-12-R/24VDC Conductive Level Controller, 1-Channel
- Brand
- TURCK
- Model
- 7545077
- GEARWELL SKU
- GWP-000022826
- Category
- Pressure, Flow & Temperature
Key specifications
- ID
- 7545077
- Outputs
- 2 x relay (change-over), ≤ 3 A, ≤ 500 VA / 60 W
- Responsivity
- 0.2 to 100 kΩ (4 ranges)
- Input circuits
- 2 or 3 electrodes
- Type designation
- MK91-12-R/24VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK 7545077 MK91-12-R/24VDC Conductive Level Controller, 1-Channel |
|---|---|
| Brand | TURCK |
| Model | 7545077 |
| Category | Pressure, Flow & Temperature |
| ID | 7545077 |
| Outputs | 2 x relay (change-over), ≤ 3 A, ≤ 500 VA / 60 W |
| Responsivity | 0.2 to 100 kΩ (4 ranges) |
| Input circuits | 2 or 3 electrodes |
| Type designation | MK91-12-R/24VDC |
| Operating voltage | 20 to 28 (nominal 24 VDC) V DC |
| Power consumption | ≤ 1.5 W |
| Ambient temperature | -25 to +60 °C |
| Dimensions / protection | 89 x 36 x 70 mm, IP20 |
| Switch-on / switch-off delay | 0 to 20 s |
