TURCK 6840029 TS-516-LUUPN8X-H1141-L050 Temp Sensor
- Brand
- TURCK
- Model
- 6840029
- GEARWELL SKU
- GWP-000022889
- Category
- Pressure, Flow & Temperature
Key specifications
- Ident-No.
- 6840029
- Voltage output
- 0...10 V
- Output function
- NO/NC programmable, PNP/NPN
- Type designation
- TS-516-LUUPN8X-H1141-L050
- Code as collected
- TS-516-LUUPN8X-H1141-L050 Turck 图尔克 温湿度产品
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK 6840029 TS-516-LUUPN8X-H1141-L050 Temp Sensor |
|---|---|
| Brand | TURCK |
| Model | 6840029 |
| Category | Pressure, Flow & Temperature |
| Ident-No. | 6840029 |
| Voltage output | 0...10 V |
| Output function | NO/NC programmable, PNP/NPN |
| Type designation | TS-516-LUUPN8X-H1141-L050 |
| Code as collected | TS-516-LUUPN8X-H1141-L050 Turck 图尔克 温湿度产品 |
| Immersion depth (L) | 50 mm |
| Measuring element | Pt100, DIN EN 60751, class A |
| Operating voltage | 18...30 VDC |
| Process connection | G 1/2″ male thread |
| Pressure resistance | 160 bar |
| Communication protocol | IO-Link |
| Temperature measuring range | -50...150 °C |
