TP-Link TL-SG1005 5-Port Gigabit Industrial L2 Managed Switch
- Brand
- TP-Link
- Model
- TL-SG1005
- GEARWELL SKU
- GWP-000012144
- Category
- Industrial Communication
Key specifications
- Mounting
- DIN rail / wall
- Dimensions
- 137 x 100 x 38 mm
- Management
- Web; broadcast storm protection, port-break alarm (DIP)
- RJ45 ports
- 5 x 10/100/1000M
- Power input
- 12/24/48 VDC (9.6 to 60 VDC), 3 redundant inputs
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TP-Link TL-SG1005 5-Port Gigabit Industrial L2 Managed Switch |
|---|---|
| Brand | TP-Link |
| Model | TL-SG1005 |
| Category | Industrial Communication |
| Mounting | DIN rail / wall |
| Dimensions | 137 x 100 x 38 mm |
| Management | Web; broadcast storm protection, port-break alarm (DIP) |
| RJ45 ports | 5 x 10/100/1000M |
| Power input | 12/24/48 VDC (9.6 to 60 VDC), 3 redundant inputs |
| Input current | 0.24 A max. |
| MAC address table | 2K |
| Protection rating | IP30 / IP40 (with supplied screws) |
| Operating temperature | -40 to 85 °C |
