TENGEN TGS51B-4/H 32A TGS51 Series Magnetic Motor Starter
- Brand
- TENGEN
- Model
- TGS51B-4/H 32A
- GEARWELL SKU
- GWP-000021269
- Category
- Contactors & Starters
Key specifications
- Version
- non-reversible (H, one contactor)
- Push buttons
- yes (LAY5-BE101/BE102)
- Starter size
- 4
- Material number
- 04070060095
- Coil control voltage
- 380 V AC 50 Hz unless otherwise specified on order
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TENGEN TGS51B-4/H 32A TGS51 Series Magnetic Motor Starter |
|---|---|
| Brand | TENGEN |
| Model | TGS51B-4/H 32A |
| Category | Contactors & Starters |
| Version | non-reversible (H, one contactor) |
| Push buttons | yes (LAY5-BE101/BE102) |
| Starter size | 4 |
| Material number | 04070060095 |
| Coil control voltage | 380 V AC 50 Hz unless otherwise specified on order |
| Max. motor power at 380 V | 20 kW |
| Rated operational current | 40 A |
| Thermal relay setting range | 20-32 A |
| Contactor / thermal relay fitted | CJT1-40 / TGR36-63 |
