TENGEN TGD1-32 17-23A TGD1 Motor Protection Circuit Breaker
- Brand
- TENGEN
- Model
- TGD1-32 17-23A
- GEARWELL SKU
- GWP-000021257
- Category
- Circuit Protection
Key specifications
- Frame size
- TGD1-32
- Trip class
- 10A
- Material number
- 04070090020
- Degree of protection
- IP20
- Icu / Ics at 400/415 V
- 15 / 6 kA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TENGEN TGD1-32 17-23A TGD1 Motor Protection Circuit Breaker |
|---|---|
| Brand | TENGEN |
| Model | TGD1-32 17-23A |
| Category | Circuit Protection |
| Frame size | TGD1-32 |
| Trip class | 10A |
| Material number | 04070090020 |
| Degree of protection | IP20 |
| Icu / Ics at 400/415 V | 15 / 6 kA |
| Thermal setting range | 17-23 A |
| Motor power AC-3 at 400 V | 11 kW |
| Trip unit rated current In | 23 A |
| Rated insulation voltage Ui | 690 V |
