TENGEN TGS51-2NH 380V 3.5A TGS51 Series Magnetic Motor Starter
- Brand
- TENGEN
- Model
- TGS51-2NH 380V 3.5A
- GEARWELL SKU
- GWP-000021260
- Category
- Contactors & Starters
Key specifications
- Version
- reversible (NH, two contactors)
- Push buttons
- no (version without buttons)
- Starter size
- 2
- Coil control voltage
- 380 V AC
- Code "TGS51-2NH 380V 3.5A"
- as collected; this exact rating code is not listed in the TENGEN online selection system, ratings from the TGS51 catalogue
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TENGEN TGS51-2NH 380V 3.5A TGS51 Series Magnetic Motor Starter |
|---|---|
| Brand | TENGEN |
| Model | TGS51-2NH 380V 3.5A |
| Category | Contactors & Starters |
| Version | reversible (NH, two contactors) |
| Push buttons | no (version without buttons) |
| Starter size | 2 |
| Coil control voltage | 380 V AC |
| Code "TGS51-2NH 380V 3.5A" | as collected; this exact rating code is not listed in the TENGEN online selection system, ratings from the TGS51 catalogue |
| Max. motor power at 380 V | 4 kW |
| Rated operational current | 10 A |
| Thermal relay setting range | 2.2-3.5 A |
| Contactor / thermal relay fitted | CJT1-10 / TGR36-32 |
| Material number (as listed by seller) | 04070060021 |
