TENGEN SG-4000VA(Cu) 380/200 SG Three-Phase Dry-Type Transformer
- Brand
- TENGEN
- Model
- SG-4000VA(Cu) 380/200
- GEARWELL SKU
- GWP-000021302
- Category
- Power Supplies
Key specifications
- Construction
- protective (enclosed) (SG)
- Input voltage
- 380 V
- Output voltage
- 200 V
- Rated capacity
- 4000 VA
- Rated frequency
- 50/60 Hz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TENGEN SG-4000VA(Cu) 380/200 SG Three-Phase Dry-Type Transformer |
|---|---|
| Brand | TENGEN |
| Model | SG-4000VA(Cu) 380/200 |
| Category | Power Supplies |
| Construction | protective (enclosed) (SG) |
| Input voltage | 380 V |
| Output voltage | 200 V |
| Rated capacity | 4000 VA |
| Rated frequency | 50/60 Hz |
| Winding material | Copper |
| Connection group options | Y/y / Y/yn / D/y (specify on order) |
| Code "SG-4000VA(Cu) 380/200" | as collected; this exact material number is not listed in the TENGEN online selection system, ratings from the SG catalogue |
| Material number (as listed by seller) | 05020090135 |
| Outline dimensions B x D x E (SG-4kVA) | 400 x 330 x 400 mm |
