TENGEN SBK-15KVA(Cu) 380/220 Y/y SBK Three-Phase Dry-Type Transformer
- Brand
- TENGEN
- Model
- SBK-15KVA(Cu) 380/220 Y/y
- GEARWELL SKU
- GWP-000021298
- Category
- Power Supplies
Key specifications
- Connection
- Y/y
- Input voltage
- 380 V
- Output voltage
- 220 V
- Rated capacity
- 15 kVA
- Material number
- 05020080982
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TENGEN SBK-15KVA(Cu) 380/220 Y/y SBK Three-Phase Dry-Type Transformer |
|---|---|
| Brand | TENGEN |
| Model | SBK-15KVA(Cu) 380/220 Y/y |
| Category | Power Supplies |
| Connection | Y/y |
| Input voltage | 380 V |
| Output voltage | 220 V |
| Rated capacity | 15 kVA |
| Material number | 05020080982 |
| Winding material | Copper |
| Official designation | SBK-15KVA(铜) 380/220 Y/y |
| Mounting dimensions A x C | 320 x 160 mm |
| Dimensions B x D x E (SBK 15 kVA) | 425 x 280 x 400 mm |
