TENGEN SBK-1000VA(Cu) 380/65 Y/yn SBK Three-Phase Dry-Type Transformer
- Brand
- TENGEN
- Model
- SBK-1000VA(Cu) 380/65 Y/yn
- GEARWELL SKU
- GWP-000021297
- Category
- Power Supplies
Key specifications
- Construction
- open (SBK)
- Input voltage
- 380 V
- Output voltage
- 65 V
- Rated capacity
- 1000 VA
- Rated frequency
- 50/60 Hz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TENGEN SBK-1000VA(Cu) 380/65 Y/yn SBK Three-Phase Dry-Type Transformer |
|---|---|
| Brand | TENGEN |
| Model | SBK-1000VA(Cu) 380/65 Y/yn |
| Category | Power Supplies |
| Construction | open (SBK) |
| Input voltage | 380 V |
| Output voltage | 65 V |
| Rated capacity | 1000 VA |
| Rated frequency | 50/60 Hz |
| Code "380/65 Y/yn" | as collected; 65 V output is outside the standard output voltages tabulated in the catalogue (660/380/220/200 V), special-order voltage |
| Connection group | Y/yn |
| Winding material | Copper |
| Material number (as listed by seller) | 343011100272 |
| Outline dimensions B x D x E (SBK-1kVA) | 185 x 160 x 185 mm |
