SMC AW20-01C-A AW10-AW40-A Series Modular Filter Regulator
- Brand
- SMC
- Model
- AW20-01C-A
- GEARWELL SKU
- GWP-000020856
- Category
- Air Preparation
Key specifications
- Option a
- Without Mounting Option
- Option b
- Float Type Auto Drain N.C.(Normally Closed)Drain Port Is Closed When Pressure Is Not Applied (code C)
- Option c
- Without Pressure Gauge
- Body Size
- Body Size (code 20)
- Port Size
- 1/8 (code 01)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AW20-01C-A AW10-AW40-A Series Modular Filter Regulator |
|---|---|
| Brand | SMC |
| Model | AW20-01C-A |
| Category | Air Preparation |
| Option a | Without Mounting Option |
| Option b | Float Type Auto Drain N.C.(Normally Closed)Drain Port Is Closed When Pressure Is Not Applied (code C) |
| Option c | Without Pressure Gauge |
| Body Size | Body Size (code 20) |
| Port Size | 1/8 (code 01) |
| Thread Type | Metric Thread (M5)/Rc |
| Semi-Standard a | 0.05 to 0.7 MPa Setting, Polycarbonate Bowl;X406:0.05 to 0.4 MPa Setting;X2068:0.05 to 0.85 MPa Setting |
| Semi-Standard b | With Drain Cock, Relieving Type, Flow Direction: Left to Right, Name Plate, Caution Plate For Bowl, And Pressure Gauge In Imperial Units: MPa |
