SMC AW20-01BG-A AW10-AW40-A Series Modular Filter Regulator
- Brand
- SMC
- Model
- AW20-01BG-A
- GEARWELL SKU
- GWP-000020855
- Category
- Air Preparation
Key specifications
- Option a
- With Bracket (code B)
- Option b
- Without Auto Drain
- Option c
- Round Type Pressure Gauge (With Limit Indicator) (code G)
- Body Size
- Body Size (code 20)
- Port Size
- 1/8 (code 01)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AW20-01BG-A AW10-AW40-A Series Modular Filter Regulator |
|---|---|
| Brand | SMC |
| Model | AW20-01BG-A |
| Category | Air Preparation |
| Option a | With Bracket (code B) |
| Option b | Without Auto Drain |
| Option c | Round Type Pressure Gauge (With Limit Indicator) (code G) |
| Body Size | Body Size (code 20) |
| Port Size | 1/8 (code 01) |
| Thread Type | Metric Thread (M5)/Rc |
| Semi-Standard a | 0.05 to 0.7 MPa Setting, Polycarbonate Bowl;X406:0.05 to 0.4 MPa Setting;X2068:0.05 to 0.85 MPa Setting |
| Semi-Standard b | With Drain Cock, Relieving Type, Flow Direction: Left to Right, Name Plate, Caution Plate For Bowl, And Pressure Gauge In Imperial Units: MPa |
