SMC AMD350C-F04D AMD Micro Mist Separator
- Brand
- SMC
- Model
- AMD350C-F04D
- GEARWELL SKU
- GWP-000020838
- Category
- Air Preparation
Key specifications
- Body size
- 350C
- Auto drain
- N.O. (D)
- Filtration
- 0.01 µm (95% particle size collection)
- Outlet oil mist
- Max. 0.1 mg/m3 (ANR)
- Pipe thread / port size
- G 1/2 (F04)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AMD350C-F04D AMD Micro Mist Separator |
|---|---|
| Brand | SMC |
| Model | AMD350C-F04D |
| Category | Air Preparation |
| Body size | 350C |
| Auto drain | N.O. (D) |
| Filtration | 0.01 µm (95% particle size collection) |
| Outlet oil mist | Max. 0.1 mg/m3 (ANR) |
| Pipe thread / port size | G 1/2 (F04) |
| Max. operating pressure | 1.0 MPa |
| Rated flow (AMD350 size) | 1000 L/min (ANR) |
| Ambient and fluid temperature | 5 to 60 °C |
