SMC AL40-02-A AL-A Modular Lubricator
- Brand
- SMC
- Model
- AL40-02-A
- GEARWELL SKU
- GWP-000020837
- Category
- Air Preparation
Key specifications
- Weight
- 0.38 kg
- Body size
- 40
- Oil capacity
- 135 cm3
- Proof pressure
- 1.5 MPa
- Pipe thread / port size
- Rc 1/4 (02)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AL40-02-A AL-A Modular Lubricator |
|---|---|
| Brand | SMC |
| Model | AL40-02-A |
| Category | Air Preparation |
| Weight | 0.38 kg |
| Body size | 40 |
| Oil capacity | 135 cm3 |
| Proof pressure | 1.5 MPa |
| Pipe thread / port size | Rc 1/4 (02) |
| Recommended lubricant | Class 1 turbine oil (ISO VG32) |
| Max. operating pressure | 1.0 MPa |
| Minimum dripping flow rate (1/4 port) | 30 L/min (ANR) |
