Siemens 6ES7153-2BA10-0XB0 ET 200M IM 153-2 HF PROFIBUS Interface Module

Key specifications

Power loss, typ.: 5.5 W
Supply voltage: 24 V DC nominal; permitted range 20.4–28.8 V DC.
Station module capacity: Up to 12 S7-300 modules in an ET 200M station; observe module compatibility rules.
Dimensions — Depth: 117 mm
Station I/O address space: 244 bytes for input data and 244 bytes for output data.

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Siemens 6ES7153-2BA10-0XB0 ET 200M IM 153-2 HF PROFIBUS Interface Module
Brand	Siemens
Model	6ES7153-2BA10-0XB0
Category	Industrial Automation Parts
Power loss, typ.	5.5 W
Supply voltage	24 V DC nominal; permitted range 20.4–28.8 V DC.
Station module capacity	Up to 12 S7-300 modules in an ET 200M station; observe module compatibility rules.
Dimensions — Depth	117 mm
Station I/O address space	244 bytes for input data and 244 bytes for output data.
PROFIBUS interface	PROFIBUS DP over RS485, up to 12 Mbit/s; 9-pin D-sub socket.
Signal time-stamp accuracy	1 ms with up to 8 modules; 10 ms with up to 12 modules.
Weights — Weight, approx.	360 g
IP degree of protection	IP20
Design of the connection	9-pin sub D socket
Product type designation	IM 153-2 DP HF
Input current — Current consumption, max.	650 mA; with 24 V DC supply
Ambient temperature during operation — horizontal installation, max.	60 °C
