SICK 6054823 TCT-1PAN40253MZ Resistance Thermometer
- Brand
- SICK
- Model
- 6054823
- GEARWELL SKU
- GWP-000022882
- Category
- Pressure, Flow & Temperature
Key specifications
- Output signal
- Pt100, 4-wire
- Article number
- 6054823
- Connection type
- M12 round connector, 4-pin
- Enclosure rating
- IP67
- Type designation
- TCT-1PAN40253MZ
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SICK 6054823 TCT-1PAN40253MZ Resistance Thermometer |
|---|---|
| Brand | SICK |
| Model | 6054823 |
| Category | Pressure, Flow & Temperature |
| Output signal | Pt100, 4-wire |
| Article number | 6054823 |
| Connection type | M12 round connector, 4-pin |
| Enclosure rating | IP67 |
| Type designation | TCT-1PAN40253MZ |
| Code as collected | 6054823 (seller title: [待拆] TCT-1PAN40253MZ Sick 西克 温湿度产品) |
| Process connection | Thread 1/4" NPT |
| Temperature measuring range | -50 ... +150 °C |
| Insertion length / probe diameter | 25 mm / 3 mm |
