SICK 1079090 KTX-WB91141259ZZZZ KTX Contrast Sensor
- Brand
- SICK
- Model
- 1079090
- GEARWELL SKU
- GWP-000024906
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Connection
- Plug, M12, 5-pin
- Light source
- LED, RGB (470/525/625 nm)
- Response time
- 10 µs
- Supply voltage
- 10.8 ... 28.8 V DC
- Light spot size
- 0.9 x 3.8 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SICK 1079090 KTX-WB91141259ZZZZ KTX Contrast Sensor |
|---|---|
| Brand | SICK |
| Model | 1079090 |
| Category | Proximity & Photoelectric Sensors |
| Connection | Plug, M12, 5-pin |
| Light source | LED, RGB (470/525/625 nm) |
| Response time | 10 µs |
| Supply voltage | 10.8 ... 28.8 V DC |
| Light spot size | 0.9 x 3.8 mm |
| Enclosure rating | IP67 |
| Sensing distance | 13 (±5) mm |
| Switching output | Push-pull: PNP/NPN |
| Type designation | KTX-WB91141259ZZZZ |
| Switching frequency | 50 kHz |
