BALLUFF BES M08EF-NSC20B-BP00,3-GS49 M8 Inductive Sensor NPN
- Brand
- BALLUFF
- Model
- BES M08EF-NSC20B-BP00,3-GS49
- GEARWELL SKU
- GWP-000024921
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Mounting
- Flush
- Connection
- 0.30 m PUR cable with M8 3-pin connector
- Order code
- BES045P
- Housing material
- Stainless steel; sensing face PBT
- Switching output
- NPN normally open (NO)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BALLUFF BES M08EF-NSC20B-BP00,3-GS49 M8 Inductive Sensor NPN |
|---|---|
| Brand | BALLUFF |
| Model | BES M08EF-NSC20B-BP00,3-GS49 |
| Category | Proximity & Photoelectric Sensors |
| Mounting | Flush |
| Connection | 0.30 m PUR cable with M8 3-pin connector |
| Order code | BES045P |
| Housing material | Stainless steel; sensing face PBT |
| Switching output | NPN normally open (NO) |
| Type designation | BES M08EF-NSC20B-BP00,3-GS49 |
| Operating voltage | 10...30 V DC |
| Switching frequency | 5000 Hz |
| Degree of protection | IP68 |
| Rated sensing distance | 2 mm |
