Captron OGLW2-70T4-2PS6 OGLW TCP Laser Measuring Instrument
- Brand
- Captron
- Model
- OGLW2-70T4-2PS6
- GEARWELL SKU
- GWP-000024970
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Outputs
- 2 x PNP-NO (X, Y), max 200 mA each, short-circuit protected
- Connection
- M8 connector, 5-pole
- Protection
- IP65
- Resolution
- 0.2 mm
- Laser light
- Red, 650 nm, class 2
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Captron OGLW2-70T4-2PS6 OGLW TCP Laser Measuring Instrument |
|---|---|
| Brand | Captron |
| Model | OGLW2-70T4-2PS6 |
| Category | Proximity & Photoelectric Sensors |
| Outputs | 2 x PNP-NO (X, Y), max 200 mA each, short-circuit protected |
| Connection | M8 connector, 5-pole |
| Protection | IP65 |
| Resolution | 0.2 mm |
| Laser light | Red, 650 nm, class 2 |
| Load current | max 50 mA |
| Repeatability | 0.01 mm |
| Supply voltage | 12 ... 30 V DC |
| Switching frequency | max 1 kHz |
| Operating temperature | +10 ... +50 °C |
