SICK 1027447 C40E-0701AN310 C4000 Eco Safety Light Curtain Receiver
- Brand
- SICK
- Model
- 1027447
- GEARWELL SKU
- GWP-000024904
- Category
- Machine Safety & Vision
Key specifications
- Weight
- 1700 g
- Resolution
- 14 mm
- System part
- Receiver
- OSSD outputs
- 2 PNP semiconductors, short-circuit protected, max. 500 mA each
- Safety level
- Type 4 (IEC 61496-1), SIL 3, PL e
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SICK 1027447 C40E-0701AN310 C4000 Eco Safety Light Curtain Receiver |
|---|---|
| Brand | SICK |
| Model | 1027447 |
| Category | Machine Safety & Vision |
| Weight | 1700 g |
| Resolution | 14 mm |
| System part | Receiver |
| OSSD outputs | 2 PNP semiconductors, short-circuit protected, max. 500 mA each |
| Safety level | Type 4 (IEC 61496-1), SIL 3, PL e |
| Scanning range | 2.5 m |
| Supply voltage | 24 V DC (19.2 ... 28.8 V) |
| Enclosure rating | IP65 |
| Type designation | C40E-0701AN310 |
| Protective field height | 750 mm |
