HONEYWELL RM7850A1001 7800 Series Burner Control Relay Module
- Brand
- HONEYWELL
- Model
- RM7850A1001
- GEARWELL SKU
- GWP-000025456
- Category
- Machine Safety & Vision
Key specifications
- Fusing
- 15 A, type SC or equivalent
- Evidence
- Honeywell specification data 66-2041-03 (hosted at cochranesupply.com)
- Burner type
- Full modulation (EC/RM7850A)
- Seller code
- RM7850A-1001
- Initiate time
- 2 s (sequence timing table)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HONEYWELL RM7850A1001 7800 Series Burner Control Relay Module |
|---|---|
| Brand | HONEYWELL |
| Model | RM7850A1001 |
| Category | Machine Safety & Vision |
| Fusing | 15 A, type SC or equivalent |
| Evidence | Honeywell specification data 66-2041-03 (hosted at cochranesupply.com) |
| Burner type | Full modulation (EC/RM7850A) |
| Seller code | RM7850A-1001 |
| Initiate time | 2 s (sequence timing table) |
| Supply voltage | 120 Vac (+10%/-15%), 50/60 Hz (±10%) |
| Power dissipation | 10 W maximum |
| Weight (relay module) | 0.730 kg |
| Operating temperature | -40 to +60 °C |
| Maximum total connected load | 2000 VA |
