HONEYWELL RM7840L1018 7800 Series Burner Control Relay Module
- Brand
- HONEYWELL
- Model
- RM7840L1018
- GEARWELL SKU
- GWP-000025455
- Category
- Machine Safety & Vision
Key specifications
- Humidity
- 85% RH continuous, noncondensing
- Mounting
- Q7800A panel mount or Q7800B wall/burner mount subbase
- Supply voltage
- 120 Vac (+10/-15%), 50/60 Hz
- Source document
- Specification Data 66-2027-04 (Honeywell document; copy hosted by distributor)
- Power dissipation
- 10 W maximum
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HONEYWELL RM7840L1018 7800 Series Burner Control Relay Module |
|---|---|
| Brand | HONEYWELL |
| Model | RM7840L1018 |
| Category | Machine Safety & Vision |
| Humidity | 85% RH continuous, noncondensing |
| Mounting | Q7800A panel mount or Q7800B wall/burner mount subbase |
| Supply voltage | 120 Vac (+10/-15%), 50/60 Hz |
| Source document | Specification Data 66-2027-04 (Honeywell document; copy hosted by distributor) |
| Power dissipation | 10 W maximum |
| Operating temperature | -40 to +60 °C |
| Weight (with dust cover) | 1 lb 13 oz |
| Flame failure response time | 0.8 or 3.0 s depending on amplifier |
| Maximum total connected load | 2000 VA |
