Setra STC1SDP100030MN Model STC Duct RTD Temperature Sensor
- Brand
- Setra
- Model
- STC1SDP100030MN
- GEARWELL SKU
- GWP-000022286
- Category
- Pressure, Flow & Temperature
Key specifications
- Housing
- ABS polycarbonate
- Output (P1)
- Pt1000 RTD, 3-wire (resistance output)
- Range (000)
- Resistance output (no transmitter range)
- Configuration (D)
- Duct mount
- Measuring type (S)
- Single point
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra STC1SDP100030MN Model STC Duct RTD Temperature Sensor |
|---|---|
| Brand | Setra |
| Model | STC1SDP100030MN |
| Category | Pressure, Flow & Temperature |
| Housing | ABS polycarbonate |
| Output (P1) | Pt1000 RTD, 3-wire (resistance output) |
| Range (000) | Resistance output (no transmitter range) |
| Configuration (D) | Duct mount |
| Measuring type (S) | Single point |
| Probe length (30M) | 300 mm |
| Mounting thread (N) | None |
| Ordering code breakdown | STC1-S-D-P1-000-30M-N |
| Sensing element accuracy | Industrial class A (EN 60751) |
| Ambient temperature (RTD output) | -40 to 85 °C |
