Setra STC1SD11MR215MN Model STC Duct Temperature Transmitter
- Brand
- Setra
- Model
- STC1SD11MR215MN
- GEARWELL SKU
- GWP-000022233
- Category
- Pressure, Flow & Temperature
Key specifications
- Housing
- ABS polycarbonate
- Output (11)
- 4 to 20 mA (2-wire transmitter)
- Range (MR2)
- -10 to 70 °C
- Supply voltage
- 12 to 28 VDC
- Configuration (D)
- Duct mount
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra STC1SD11MR215MN Model STC Duct Temperature Transmitter |
|---|---|
| Brand | Setra |
| Model | STC1SD11MR215MN |
| Category | Pressure, Flow & Temperature |
| Housing | ABS polycarbonate |
| Output (11) | 4 to 20 mA (2-wire transmitter) |
| Range (MR2) | -10 to 70 °C |
| Supply voltage | 12 to 28 VDC |
| Configuration (D) | Duct mount |
| Probe length (15M) | 150 mm |
| Mounting thread (N) | None |
| Accuracy (transmitter) | ±0.2 °C @ 20 °C |
| Ordering code breakdown | STC1-S-D-11-MR2-15M-N |
| Ambient temperature (transmitter) | 0 to 70 °C |
