Setra STC1SI11MR205MG1 Model STC Immersion Temperature Transmitter
- Brand
- Setra
- Model
- STC1SI11MR205MG1
- GEARWELL SKU
- GWP-000022288
- Category
- Pressure, Flow & Temperature
Key specifications
- Output (11)
- 4 to 20 mA (2-wire transmitter)
- Range (MR2)
- -10 to 70 °C
- Seller code
- STC1Sl11MR205MG1 (lowercase l read as I = water-pipe configuration)
- Supply voltage
- 12 to 28 VDC
- Configuration (I)
- Water-pipe (immersion) mount
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra STC1SI11MR205MG1 Model STC Immersion Temperature Transmitter |
|---|---|
| Brand | Setra |
| Model | STC1SI11MR205MG1 |
| Category | Pressure, Flow & Temperature |
| Output (11) | 4 to 20 mA (2-wire transmitter) |
| Range (MR2) | -10 to 70 °C |
| Seller code | STC1Sl11MR205MG1 (lowercase l read as I = water-pipe configuration) |
| Supply voltage | 12 to 28 VDC |
| Configuration (I) | Water-pipe (immersion) mount |
| Probe length (05M) | 50 mm |
| Mounting thread (G1) | G1/2" |
| Accuracy (transmitter) | ±0.2 °C @ 20 °C |
| Ordering code breakdown | STC1-S-I-11-MR2-05M-G1 |
| Ambient temperature (transmitter) | 0 to 70 °C |
