Setra STC1-S-I-P2-000-10M-1T STC Immersion RTD Temperature Sensor
- Brand
- Setra
- Model
- STC1-S-I-P2-000-10M-1T
- GEARWELL SKU
- GWP-000022231
- Category
- Pressure, Flow & Temperature
Key specifications
- Housing
- Aluminium alloy; 304 stainless steel sensor sheath
- Output (P2)
- Pt100 RTD, 3-wire (resistance output)
- Range (000)
- Resistance output (no transmitter range)
- Configuration (I)
- Water-pipe (immersion) mount
- Measuring type (S)
- Single point
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra STC1-S-I-P2-000-10M-1T STC Immersion RTD Temperature Sensor |
|---|---|
| Brand | Setra |
| Model | STC1-S-I-P2-000-10M-1T |
| Category | Pressure, Flow & Temperature |
| Housing | Aluminium alloy; 304 stainless steel sensor sheath |
| Output (P2) | Pt100 RTD, 3-wire (resistance output) |
| Range (000) | Resistance output (no transmitter range) |
| Configuration (I) | Water-pipe (immersion) mount |
| Measuring type (S) | Single point |
| Probe length (10M) | 100 mm |
| Mounting thread (1T) | 1/2" NPT |
| Ordering code breakdown | STC1-S-I-P2-000-10M-1T |
| Sensing element accuracy | Industrial class A (IEC 751) |
| Ambient temperature (RTD output) | -40 to 85 °C |
