Schneider Electric SM-070/60/010/P1/45/S1/B0 PacDrive SM servo motor (ELAU) AC synchronous servo motor
- Brand
- Schneider Electric
- Model
- SM-070/60/010/P1/45/S1/B0
- GEARWELL SKU
- GWP-000032011
- Category
- Servo Systems
Key specifications
- Mass
- 2.75 kg
- Peak torque
- 4.7 Nm
- Rated power
- 0.7 kW
- Rated speed
- 6000 rpm
- Peak current
- 6.0 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric SM-070/60/010/P1/45/S1/B0 PacDrive SM servo motor (ELAU) AC synchronous servo motor |
|---|---|
| Brand | Schneider Electric |
| Model | SM-070/60/010/P1/45/S1/B0 |
| Category | Servo Systems |
| Mass | 2.75 kg |
| Peak torque | 4.7 Nm |
| Rated power | 0.7 kW |
| Rated speed | 6000 rpm |
| Peak current | 6.0 A |
| Options (type key) | P1 keyed shaft DIN 6885; 45 = IP64 shaft / IP65 housing; S1 SinCos single-turn; B0 no brake |
| Standstill current | 1.43 A |
| Standstill torque M0 | 1.1 Nm |
