Schneider Electric BSH1403P12F2A Lexium 15, Lexium 05 Servo motor
- Brand
- Schneider Electric
- Model
- BSH1403P12F2A
- GEARWELL SKU
- GWP-000031929
- Category
- Servo Systems
Key specifications
- Feedback type
- Multiturn SinCos Hiperface
- Holding brake
- With
- Nominal speed
- 1500 rpm for LXM15MD40N4, 230 V, three phase
- Peak stall torque
- 41.6 N.M for LXM15MD40N4, 230 V, three phase
- Nominal output power
- 3400 W for LXM15MD56N4, 480 V, three phase
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric BSH1403P12F2A Lexium 15, Lexium 05 Servo motor |
|---|---|
| Brand | Schneider Electric |
| Model | BSH1403P12F2A |
| Category | Servo Systems |
| Feedback type | Multiturn SinCos Hiperface |
| Holding brake | With |
| Nominal speed | 1500 rpm for LXM15MD40N4, 230 V, three phase |
| Peak stall torque | 41.6 N.M for LXM15MD40N4, 230 V, three phase |
| Nominal output power | 3400 W for LXM15MD56N4, 480 V, three phase |
| Continuous stall torque | 25.4 N.M for LXM05AD57N4, 380...480 V, three phase |
| Maximum mechanical speed | 4000 Rpm |
| Product or component type | Servo motor |
