Schneider Electric BSH1004T31F2A Lexium 15 Servo motor
- Brand
- Schneider Electric
- Model
- BSH1004T31F2A
- GEARWELL SKU
- GWP-000031925
- Category
- Servo Systems
Key specifications
- Feedback type
- Single turn SinCos Hiperface
- Holding brake
- With
- Nominal speed
- 3500 rpm for LXM15LD28M3, 230 V, three phase
- Peak stall torque
- 15.7 N.M for LXM15LD28M3, 230 V, three phase
- Nominal output power
- 2500 W for LXM15LD28M3, 230 V, three phase
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric BSH1004T31F2A Lexium 15 Servo motor |
|---|---|
| Brand | Schneider Electric |
| Model | BSH1004T31F2A |
| Category | Servo Systems |
| Feedback type | Single turn SinCos Hiperface |
| Holding brake | With |
| Nominal speed | 3500 rpm for LXM15LD28M3, 230 V, three phase |
| Peak stall torque | 15.7 N.M for LXM15LD28M3, 230 V, three phase |
| Nominal output power | 2500 W for LXM15LD28M3, 230 V, three phase |
| Continuous stall torque | 9.31 N.M for LXM15MD40N4, 230 V, three phase |
| Maximum mechanical speed | 6000 Rpm |
| Product or component type | Servo motor |
