Schneider Electric BSH1402T32A1P Lexium 32, Lexium 05 Servo motor
- Brand
- Schneider Electric
- Model
- BSH1402T32A1P
- GEARWELL SKU
- GWP-000031928
- Category
- Servo Systems
Key specifications
- Feedback type
- Multiturn SinCos Hiperface
- Holding brake
- Without
- Nominal speed
- 3000 rpm for LXM32.D72N4 at 24 A, 400 V, three phase
- Peak stall torque
- 59.3 N.M for LXM32.D72N4 at 24 A, 400 V, three phase
- Nominal output power
- 3900 W for LXM32.D72N4 at 24 A, 400 V, three phase
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric BSH1402T32A1P Lexium 32, Lexium 05 Servo motor |
|---|---|
| Brand | Schneider Electric |
| Model | BSH1402T32A1P |
| Category | Servo Systems |
| Feedback type | Multiturn SinCos Hiperface |
| Holding brake | Without |
| Nominal speed | 3000 rpm for LXM32.D72N4 at 24 A, 400 V, three phase |
| Peak stall torque | 59.3 N.M for LXM32.D72N4 at 24 A, 400 V, three phase |
| Nominal output power | 3900 W for LXM32.D72N4 at 24 A, 400 V, three phase |
| Continuous stall torque | 19.5 N.M for LXM32.D72N4 at 24 A, 400 V, three phase |
| Maximum mechanical speed | 4000 Rpm |
| Product or component type | Servo motor |
