Schneider Electric 140AVI03000 Modicon Quantum automation platform Analog input module

Key specifications

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Schneider Electric 140AVI03000 Modicon Quantum automation platform Analog input module
Brand	Schneider Electric
Model	140AVI03000
Category	PLCs & I/O
Fault type	Broken wire 4...20 mA / Overtacking scale 1...5 V
Input type	Differential
Net weight	0.3 Kg
Update time	10 Ms
Type of filter	Single pole low pass - 3 dB at 847 Hz +/- 20 %
Input impedance	> 20 Ohm voltage / 250 MOhm +/- 0.03 %
Linearity error	+/- 0.008 %
Analogue input type	Bipolar current: 20 mA / Bipolar voltage: +/- 10 V / Bipolar voltage: +/- 5 V / Unipolar current: 0...20 mA / Unipolar voltage: 0...10 V / Unipolar voltage: 0...5 V
Analogue input number	8
Common mode rejection	> - 80 dB 60 Hz
Absolute maximum input	50 V DC / 25 mA
Addressing requirement	9 input words
Linear measuring range	(Input range) x 1.024 mA / (Input range) x 1.024 V
Power dissipation in W	2.2 W
Absolute accuracy error	+/- 0.03 % / +/- 0.05 % of full scale maximum
Bus current requirement	280 MA
Analogue input resolution	16 bits +/- 10 V / 16 bits +/- 5 V / 16 bits 0...10 V / 16 bits 0...20 mA / 16 bits 0...5 V / 16 bits 20 mA
Isolation between channels	135 Vrms AC / 200 V DC
Isolation between channels and bus	500 Vrms AC for 60 s / 750 V DC
Accuracy drift according to temperature	+/- 0.0015 % of full scale/°C / <= 0.004 % of full scale /°C
