RITTAL SV9346.000 Switch
- Brand
- RITTAL
- Model
- SV9346.000 SV
- GEARWELL SKU
- GWP-000000885
- Category
- Industrial Automation Parts
Key specifications
- NH fuse size
- 00
- Dimensions
- 50 × 400 mm (W × H)
- Product type
- NH slimline fuse-switch disconnector
- Busbar centre spacing
- 60 mm
- Round conductor range
- 2.5–95 mm²
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | RITTAL SV9346.000 Switch |
|---|---|
| Brand | RITTAL |
| Model | SV9346.000 SV |
| Category | Industrial Automation Parts |
| NH fuse size | 00 |
| Dimensions | 50 × 400 mm (W × H) |
| Product type | NH slimline fuse-switch disconnector |
| Busbar centre spacing | 60 mm |
| Round conductor range | 2.5–95 mm² |
| Connection type | Box terminal |
| Rated operating current | 160 A maximum |
| Rated operating voltage | 690 VAC, 3-phase |
