RITTAL SK 3110000 SK Enclosure Internal Thermostat
- Brand
- RITTAL
- Model
- SK 3110000
- GEARWELL SKU
- GWP-000022831
- Category
- Filtration & Accessories
Key specifications
- EAN
- 4028177036598
- Colour
- RAL 7035
- Contact
- Single-pole change-over, quick-break
- Net weight
- 0.095 kg
- Setting range
- 5 to 60 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | RITTAL SK 3110000 SK Enclosure Internal Thermostat |
|---|---|
| Brand | RITTAL |
| Model | SK 3110000 |
| Category | Filtration & Accessories |
| EAN | 4028177036598 |
| Colour | RAL 7035 |
| Contact | Single-pole change-over, quick-break |
| Net weight | 0.095 kg |
| Setting range | 5 to 60 °C |
| Article number | SK 3110000 |
| Dimensions (W x H x D) | 71 x 71 x 33.5 mm |
| Switching difference | approx. 1 K ± 0.8 K |
| Rated operating voltage | 24-230 V AC, 1~; 24-60 V DC |
| Permissible contact load | Heating AC 10 (4) A; cooling AC 5 (4) A; DC max. 30 W |
