RICOH FL-CC1614-5M 16mm F1.4 C-Mount Machine Vision Lens
- Brand
- RICOH
- Model
- FL-CC1614-5M
- GEARWELL SKU
- GWP-000020574
- Category
- Machine Safety & Vision
Key specifications
- Mount
- C-Mount (1-32UN-2A)
- Format
- 2/3" (8.8 x 6.6 mm)
- Iris range
- F1.4 to F16
- Focal length
- 16 mm
- Max. aperture
- F1.4
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | RICOH FL-CC1614-5M 16mm F1.4 C-Mount Machine Vision Lens |
|---|---|
| Brand | RICOH |
| Model | FL-CC1614-5M |
| Category | Machine Safety & Vision |
| Mount | C-Mount (1-32UN-2A) |
| Format | 2/3" (8.8 x 6.6 mm) |
| Iris range | F1.4 to F16 |
| Focal length | 16 mm |
| Max. aperture | F1.4 |
| Filter thread | M40.5 x 0.5 mm |
| Min. pixel pitch | 3.45 um |
| Dimensions / weight | dia. 43 x 47 mm / 140 g |
| Maker identification | RICOH FA lens; RICOH spec sheet FL-CC1614-5M (2012) and current OPTOWL (Ricoh FA lens successor) 2026 catalogue list this part; Baumer resells it as accessory ZVL-FL-CC1614-5M |
| Angle of view (D x H x V) | 37.9 x 30.8 x 23.4 deg |
| Minimum object distance | 0.1 m |
