Pepperl+Fuchs ECN20IL-05A1A-X1 ECN20IL Cable Pull, 5 m, Servo Flange
- Brand
- Pepperl+Fuchs
- Model
- ECN20IL-05A1A-X1
- GEARWELL SKU
- GWP-000022698
- Category
- Encoders & Position
Key specifications
- Rope
- Stainless steel 1.4401/316, Ø 0.55 mm
- Material
- A: anodized aluminum
- Cable mount
- A: ring PE carrier
- Flange type
- X1: servo flange Ø 50 mm/42 mm/3 x M4; shaft Ø 6 mm x 10 mm
- Product status
- Archived (P+F search API)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Pepperl+Fuchs ECN20IL-05A1A-X1 ECN20IL Cable Pull, 5 m, Servo Flange |
|---|---|
| Brand | Pepperl+Fuchs |
| Model | ECN20IL-05A1A-X1 |
| Category | Encoders & Position |
| Rope | Stainless steel 1.4401/316, Ø 0.55 mm |
| Material | A: anodized aluminum |
| Cable mount | A: ring PE carrier |
| Flange type | X1: servo flange Ø 50 mm/42 mm/3 x M4; shaft Ø 6 mm x 10 mm |
| Product status | Archived (P+F search API) |
| Repeatability (5 m) | max. 0.5 mm |
| Weight (design 130) | 2.6 kg |
| Ambient temperature | -30 ... 70 °C |
| Degree of protection | IP64 |
| Measuring cable length | 5 (type code 05, design 130) m |
