People Electric RDCPS(KBO)-45C/M16/06M CPS Switching Device

Key specifications

Frame current: 45 A
Controller type: M - economic type intelligent controller
Material number: 101002012010026
Auxiliary contacts: 3 NO + 3 NC + 1 short-circuit signal + 1 fault signal (code 06)
Motor power at 380 V: 4.4-6.5 kW

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	People Electric RDCPS(KBO)-45C/M16/06M CPS Switching Device
Brand	People Electric
Model	RDCPS(KBO)-45C/M16/06M
Category	Contactors & Starters
Frame current	45 A
Controller type	M - economic type intelligent controller
Material number	101002012010026
Auxiliary contacts	3 NO + 3 NC + 1 short-circuit signal + 1 fault signal (code 06)
Motor power at 380 V	4.4-6.5 kW
Control supply voltage	AC 220 V
Breaking capacity class	C (Ics 12 kA at 380 V)
Controller rated current Ie	16 A
Long-delay setting current Ir	5.4-16 A
Rated operational / insulation voltage	400 / 690 V
