People Electric RDCPS(KBO)-125C/M63/02MF CPS Switching Device
- Brand
- People Electric
- Model
- RDCPS(KBO)-125C/M63/02MF
- GEARWELL SKU
- GWP-000020681
- Category
- Contactors & Starters
Key specifications
- Derived code
- F - fire-fighting type
- Frame current
- 125 A
- Code suffix "02"
- as collected; not listed in the official model-number table (auxiliary contact codes 06 / 09)
- Controller type
- M - economic type intelligent controller
- Material number
- 101002012010020
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | People Electric RDCPS(KBO)-125C/M63/02MF CPS Switching Device |
|---|---|
| Brand | People Electric |
| Model | RDCPS(KBO)-125C/M63/02MF |
| Category | Contactors & Starters |
| Derived code | F - fire-fighting type |
| Frame current | 125 A |
| Code suffix "02" | as collected; not listed in the official model-number table (auxiliary contact codes 06 / 09) |
| Controller type | M - economic type intelligent controller |
| Material number | 101002012010020 |
| Motor power at 380 V | 17-26 kW |
| Control supply voltage | AC 220 V |
| Breaking capacity class | C (Ics 12 kA at 380 V) |
| Controller rated current Ie | 63 A |
| Long-delay setting current Ir | 21-63 A |
