People Electric RDCPS(KBO)-45C/M2/06MF CPS Switching Device

Key specifications

Derived code: F - fire-fighting type
Frame current: 45 A
Controller type: M - economic type intelligent controller
Material number: 101002012010072
Auxiliary contacts: 3 NO + 3 NC + 1 short-circuit signal + 1 fault signal (code 06)

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	People Electric RDCPS(KBO)-45C/M2/06MF CPS Switching Device
Brand	People Electric
Model	RDCPS(KBO)-45C/M2/06MF
Category	Contactors & Starters
Derived code	F - fire-fighting type
Frame current	45 A
Controller type	M - economic type intelligent controller
Material number	101002012010072
Auxiliary contacts	3 NO + 3 NC + 1 short-circuit signal + 1 fault signal (code 06)
Motor power at 380 V	0.4-0.9 kW
Control supply voltage	AC 220 V
Breaking capacity class	C (Ics 12 kA at 380 V)
Controller rated current Ie	2 A
Long-delay setting current Ir	0.8-2 A
