OPTEX BA-30TA-S BA Series Infrared Thermometer, 4-20 mA
- Brand
- OPTEX
- Model
- BA-30TA-S
- GEARWELL SKU
- GWP-000021648
- Category
- Pressure, Flow & Temperature
Key specifications
- Accuracy
- ±1% or ±2 °C of reading, whichever is greater
- Analog output
- 4 to 20 mA, scalable
- Field of view
- ø30 mm / 1000 mm
- Response time
- 0.1 s / 90%
- Supply voltage
- 12 to 24 VDC ±10%
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OPTEX BA-30TA-S BA Series Infrared Thermometer, 4-20 mA |
|---|---|
| Brand | OPTEX |
| Model | BA-30TA-S |
| Category | Pressure, Flow & Temperature |
| Accuracy | ±1% or ±2 °C of reading, whichever is greater |
| Analog output | 4 to 20 mA, scalable |
| Field of view | ø30 mm / 1000 mm |
| Response time | 0.1 s / 90% |
| Supply voltage | 12 to 24 VDC ±10% |
| Measurement range | 0 to 500 °C |
| Ambient temperature | 0 to 50 °C |
| Degree of protection | IP65 |
| Emissivity adjustment | 0.10 to 1.20 |
| Sensing element / spectral response | Thermopile / 8 to 14 µm |
