OPTEX SA-80T-4A-3 SA-80 Series Infrared Thermometer, 0-400 °C

Key specifications

Output: Analog 4 to 20 mA
Code suffix "-3": as collected; not listed in the official model-number table (official type SA-80T-4A has a 2 m cable)
Field of view: ø80 / 500 mm
Response time: 100 ms / 90%
Supply voltage: 12 to 24 VDC ±10%

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	OPTEX SA-80T-4A-3 SA-80 Series Infrared Thermometer, 0-400 °C
Brand	OPTEX
Model	SA-80T-4A-3
Category	Pressure, Flow & Temperature
Output	Analog 4 to 20 mA
Code suffix "-3"	as collected; not listed in the official model-number table (official type SA-80T-4A has a 2 m cable)
Field of view	ø80 / 500 mm
Response time	100 ms / 90%
Supply voltage	12 to 24 VDC ±10%
Measurement range	0 to +400 °C
Ambient temperature	0 to +70 °C
Degree of protection	IP67
Sensing element / spectral response	Thermopile / 8 to 14 µm
