OMRON EE-SX47 Photo Micro Sensor
- Brand
- OMRON
- Model
- EE-SX47
- GEARWELL SKU
- GWP-000000304
- Category
- Industrial Automation Parts
Key specifications
- Light source
- Infrared LED, 940 nm peak
- Product type
- Slot-type photomicrosensor, non-modulated
- Sensing method
- Through-beam with slot
- Minimum sensing object
- Opaque object, 2 × 0.8 mm
- Supply voltage
- 5 to 24 VDC ±10%
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMRON EE-SX47 Photo Micro Sensor |
|---|---|
| Brand | OMRON |
| Model | EE-SX47 |
| Category | Industrial Automation Parts |
| Light source | Infrared LED, 940 nm peak |
| Product type | Slot-type photomicrosensor, non-modulated |
| Sensing method | Through-beam with slot |
| Minimum sensing object | Opaque object, 2 × 0.8 mm |
| Supply voltage | 5 to 24 VDC ±10% |
| Sensing distance | 5 mm slot width |
| Response frequency | 1 kHz minimum (3 kHz average) |
| Degree of protection | IEC 60529 IP50 |
