OMRON CP1W-TS001 Analogue Expansion Unit
- Brand
- OMRON
- Model
- CP1W-TS001
- GEARWELL SKU
- GWP-000000641
- Category
- Industrial Automation Parts
Key specifications
- Accuracy
- Greater of ±0.5% of converted value or ±2 °C, ±1 digit maximum
- Converted data format
- 16-bit binary data
- Sensor type
- Thermocouple, selectable K or J
- Product type
- Temperature sensor input unit
- Input channels
- 2
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The OMRON CP1W-TS001 is a CP1W Expansion Unit with 2 thermocouple inputs, switchable between K and J (the same type for both inputs), with the range set by a rotary switch. Conversion takes 250 ms and accuracy at 25°C is the larger of ±0.5% of the converted value or ±2°C, ±1 digit max. The inputs are isolated by photocouplers. It draws 40 mA max. at 5 VDC and 59 mA max. at 24 VDC.
Technical reference
| Product name | OMRON CP1W-TS001 Analogue Expansion Unit |
|---|---|
| Brand | OMRON |
| Model | CP1W-TS001 |
| Category | Industrial Automation Parts |
| Accuracy | Greater of ±0.5% of converted value or ±2 °C, ±1 digit maximum |
| Converted data format | 16-bit binary data |
| Sensor type | Thermocouple, selectable K or J |
| Product type | Temperature sensor input unit |
| Input channels | 2 |
| Conversion time | 250 ms for 2 input points |
| Current consumption | 40 mA max. at 5 VDC; 59 mA max. at 24 VDC |
| Allocated input words | 2 |
