OMEGA HX94CNPT HX94 Duct-Mount RH/Temperature Transmitter
- Brand
- OMEGA
- Model
- HX94CNPT
- GEARWELL SKU
- GWP-000022745
- Category
- Pressure, Flow & Temperature
Key specifications
- Probe
- 254 x 19 mm dia., 305 mm cable
- Output
- 4 to 20 mA (0-100% RH / 0-100 °C)
- Housing
- Stainless steel NEMA 4
- Evidence
- OMEGA HX94 Series datasheet page Hu-32 (hosted at farnell.com)
- Connection
- 1/2" male NPT fitting with 1 m (3 ft) braided/shielded cable
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMEGA HX94CNPT HX94 Duct-Mount RH/Temperature Transmitter |
|---|---|
| Brand | OMEGA |
| Model | HX94CNPT |
| Category | Pressure, Flow & Temperature |
| Probe | 254 x 19 mm dia., 305 mm cable |
| Output | 4 to 20 mA (0-100% RH / 0-100 °C) |
| Housing | Stainless steel NEMA 4 |
| Evidence | OMEGA HX94 Series datasheet page Hu-32 (hosted at farnell.com) |
| Connection | 1/2" male NPT fitting with 1 m (3 ft) braided/shielded cable |
| Input voltage | 6 to 30 Vdc (polarity protected) |
| RH range / accuracy | 3 to 95% RH / ±2% RH |
| Temperature sensor | Thin-film 100 Ω platinum RTD (DIN 43760) |
| Temperature range / accuracy | 0 to 100 °C / ±0.6 °C |
