OMEGA HX93BC-RP1 HX93B Remote Probe Temperature/RH Transmitter
- Brand
- OMEGA
- Model
- HX93BC-RP1
- GEARWELL SKU
- GWP-000022744
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- 4 to 20 mA
- Weight
- 352 g
- Enclosure
- Gray polycarbonate, NEMA 13 (IP54)
- Input power
- 9 to 30 Vdc @ 100 mA
- Probe cable
- 3 m (10 ft), remote probe
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMEGA HX93BC-RP1 HX93B Remote Probe Temperature/RH Transmitter |
|---|---|
| Brand | OMEGA |
| Model | HX93BC-RP1 |
| Category | Pressure, Flow & Temperature |
| Output | 4 to 20 mA |
| Weight | 352 g |
| Enclosure | Gray polycarbonate, NEMA 13 (IP54) |
| Input power | 9 to 30 Vdc @ 100 mA |
| Probe cable | 3 m (10 ft), remote probe |
| RH accuracy | ±2.5% (20 to 80% RH) |
| Temperature range | -30 to 75 °C |
| RH measuring range | 0 to 100 % RH |
| Temperature accuracy | ±0.6 °C (0 to 50 °C) |
