National Instruments PXI-4071 PXI Digital Multimeter Module
- Brand
- National Instruments
- Model
- PXI-4071
- GEARWELL SKU
- GWP-000019158
- Category
- Test & Measurement
Key specifications
- Interface
- PXI
- Resolution
- 7½ digits
- Form factor
- 3U
- AC current range
- 3 A
- AC voltage range
- 1000 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | National Instruments PXI-4071 PXI Digital Multimeter Module |
|---|---|
| Brand | National Instruments |
| Model | PXI-4071 |
| Category | Test & Measurement |
| Interface | PXI |
| Resolution | 7½ digits |
| Form factor | 3U |
| AC current range | 3 A |
| AC voltage range | 1000 V |
| DC current range | ±3 A |
| DC voltage range | ±1000 V |
| Resistance range | 10 Ω to 5 GΩ |
| Specification note | Specifications from supplier data; please verify against the nameplate before ordering. |
| Digitizer sample rate | 1.8 MS/s |
| Operating temperature | 0 to 55 °C |
| Frequency/period range | 1 Hz to 300 kHz |
